High-efficiency active balancing
Bi-directional energy transfer topology to rapidly minimize cell voltage differentials.
Smart tri-mode operation
Automated switching between charge, discharge, and balancing, supporting seamless CC/CV transition.
Isolated channel management
Synchronous multi-channel paralleling with independent string regulation and zero mutual interference.
Intelligent balancing strategic
The tester features targeted energy replenishment and real-time SOH assessment for optimized battery longevity.
Rapid adaptation
Equipped with diverse pre-configured battery templates for one-click parameter recall, making test profile switching effortless and efficient.
TECHNICAL PARAMETERS
| Model | DEVB-24TD | DEVB-36TD | DEVB-48TD | DEVB-60TD |
| Input Voltage | 110V / 220V AC (50/60Hz) | |||
| Channel | 1–24CH | 1–36CH | 1–48CH | 1–60CH |
| Output Voltage Range | 0.5V – 4.5V DC | |||
| Output Current Range | 0.1 – 5A | |||
| Voltage Measurement Accuracy | ±2mV | |||
| Current Measurement Accuracy | ±50mA | |||
| Max.Output Power | 25W/CH | 25W/CH | 25W/CH | 25W/CH |
| Grid Protection | Undervoltage, overvoltage, overcurrent, short circuit, and phase-loss protection | |||
| Battery Protection | Undervoltage, overvoltage, overcurrent, short circuit, and reverse polarity protection | |||
| Data Display | Real-time display of individual cell status, fault alarms, operation status, and run time | |||
| Data Storage | Exports voltage, current, temperature, and cell data during balancing | |||
| Altitude | 2000M | |||
| Ambient Temperature | -20°C to +55°C | |||
| Max. Relative Humidity | 0–95% RH (non-condensing) | |||
| IP | IP20 | |||
| Cooling Method | Air Cooling | |||
Dimension (W×D×H) mm | 464×243×221 | 464×343×221 | 464×343×221 | 464×398×221 |
