| Item | Specification |
| AC Input Power | |
| Input Voltage | 320~440Vac (50/60Hz ±5Hz) |
| Output Voltage Range | 60V~1000Vdc, supports 0V charging |
| Output Current Range | -50~50A |
| Output Channel | |
| Voltage Measurement Accuracy | ±0.05% FS |
| Current Measurement Accuracy | ±0.05% FS |
| Maximum Output Power | 15kW |
| Output Quality | |
| Voltage Ripple | ≤0.5% FS |
| Current Ripple | ≤5% |
| Power Quality | |
| Power Factor | ≥0.99 |
| Conversion Efficiency | ≥90% |
| Harmonic Distortion | ≤5% |
| Auxiliary Channels | |
| Temperature Measurement Channel (optional) | -40°C~120°C, 3-channel optional, accuracy ±1°C |
| Voltage Measurement Channel (optional) | -8~8V, 12-channel optional, accuracy ±1.5mV |
| Protection Functions | |
| Software Protection | Under-voltage, over-voltage, over-current, over-temperature, reverse connection, insulation protection |
| Hardware Protection | Under-voltage, over-voltage, over-current, over-temperature, reverse connection, hardware insulation protection |
| Environmental Conditions | |
| Altitude | ≤3000m |
| Ambient Temperature | 0~25°C |
| Relative Humidity | 0~80% RH (non-condensing) |
| Protection Grade | IP20 |
| Cooling Method | Forced Air Cooling |
| Mechanical Structure | |
| Dimensions (W×D×H) | 400mm × 600mm × 500mm |
| (Other sizes available upon request.) | |
