| Content | Parameter |
|---|---|
| Input AC Power | Input Voltage: 320~440Vac (50/60Hz ±5Hz) |
| Output Voltage Range: 30V~500Vdc, supports 0V output | |
| Output Current Range: -50~50A | |
| Output Channel | Voltage Accuracy: ±0.05%FS |
| Current Accuracy: ±0.05%FS | |
| Voltage Resolution: 0.1mV | |
| Current Resolution: 0.1mA | |
| Power Accuracy: 0.05%FS | |
| Output Quality | Voltage Ripple: ≤0.5%FS |
| Current Ripple: ≤0.5%FS | |
| Power Supply Quality | Voltage Overshoot: ≤5% |
| Response Time: ≤1ms | |
| Auxiliary Channel | Temperature Measurement (Optional): -40℃~120℃, supports 2-wire/3-wire/4-wire, accuracy ±1℃ |
| Battery Voltage Acquisition (Optional): -8~8V, accuracy ±1.5mV | |
| Protection Functions | Basic Protections: OVP, UVP, OCP, UCP, OPP, OTP |
| Safety Protections: Reverse connection, relay fault, insulation fault | |
| Cooling Method | Forced air cooling |
| Environmental Conditions | Altitude: ≤3000m |
| Operating Temperature: -20~55℃ | |
| Max Relative Humidity: 0~80% (non-condensing) | |
| Protection Level | IP20 |
| Mechanical Parameters | Dimensions (W×H×D): 250mm × 530mm × 290mm |
(Customizable options available upon request)
